Atomic Pro Kira Line Array with 2 Sub 18" and 6 Top 10"

The Atomic Pro Kira Line Array is a complete professional audio system, consisting of two 18" Subwoofers and six 10" heads. The complex of top quality elements reaches a frightening power, ideal for large installations, stages, pavilions, large open spaces. The system is complete with support structures for hanging .

  • Complete Line Array sound system for medium/large rooms and tours
  • Includes two 18" subwoofers and six 10" heads
  • Complete with two fliyng bars for hanging
  • Easy to set up, compact and versatile
2 years Warranty

Do you need help?

Contact our support team!

The Atomic Pro Kira Line Array is a complete professional audio system, consisting of two 18" subwoofers and six 10" tops. The complex of extremely high-quality elements guarantees the ideal power and efficiency for large-scale systems, stages, pavilions and large open spaces. The system is complete with a flying bar for hanging .

The integrated DSP offers extensive signal control and easy-to-setup functions such as Low Cut, Coupling Compensation and High Frenquency Compensation.
Selecting HFC1 or HFC2 allows you to compensate for the loss of high-frequency energy due to air absorption when the speakers are used to cover distant listening positions. When selecting the HFC1 or HFC2 function, a coupling compensation has been developed. This CPL function compensates for coupling effects between cabinets in an array. The CPL attenuation can be adjusted internally via the USB port.

Kira Series Line Array

The Kira series is a compact size, high power line array system developed for mid-sized touring. The Atomic Pro engineering team has developed a line array system that is easy to set up, compact and versatile. Fully powered, with onboard digital controller (DSP) and high quality components, the Kira Series is the result of Atomic Pro's long experience in speaker cabinet design and manufacturing. The tight coupling of the components ensures uniform vertical dispersion and increases the coherence of sound . Presets including gain, equalization, coupling compensation and high frequency compensation can be easily selected, allowing for quick setup for near/mid-field and far-field positions.

Atomic Pro Kira Sub18

The Kira Line Array comprises two 18-inch subwoofers from Atomic Pro's Kira series. The Kira K18 is an active subwoofer featuring a high-performance 18-inch ferrite driver housed in a bass reflex enclosure , perfectly tuned for ultra-low frequency response Class D integrated amplifier with DSP (1000W RMS) offers high power and all the necessary functions for easy setup, such as crossover frequency and phase adjustment.

Atomic Pro Kira Top 10

The Kira Line Array consists of six bi-amplified 10" Kira tops, equipped with a high quality neodymium woofer with voice coil and a 3" HF driver, each capable of delivering a power of 350W RMS.
The mechanical design offers vertical adjustment from 0 to 10° with an adjustment of 1° per step. With a spectrum coverage of 100°x15° (HxV), the Kira Top10 offers precise and fair dispersion from 20Hz to 20,000Hz.

Thanks to the powerful Class D switching power amplifier module and the integrated DSP with its own system presets, setting up your line array system becomes simple. The ultra-compact and solid chassis, made from high quality 18mm plywood, is finished in a long lasting water-based varnish for touring use.

Features Atomic Pro Kira Line Array

  • Complete Line Array sound system for medium/large rooms and tours
  • Includes two 18" subwoofers and six 10" heads
  • Complete with two fliyng bars for hanging
  • Easy to set up, compact and versatile

Features Atomic Pro Kira Sub18 subwoofer

  • Wooden structure
  • Perforated metal grille
  • High performance 18'' ferrite driver
  • Class-D amplifier with DSP
  • Sensitivity adjustable from 0dB to 10dB.
  • Adjustable crossover control from 70Hz to 120Hz
  • Power indicator
  • Signal indicator
  • Limiter indicator
  • Phase switch to invert the phase of the subwoofer output to the input signal
  • XLR line input
  • Line output
  • LINK/X-OVER output switch
  • USB port
  • Power switch
  • Power In/Out

Atomic Pro Kira Top10 head features

  • Wooden construction
  • Horn loaded linear source HF driver with 1.4 throat and 3 inch voice coil
  • Perforated metal grille
  • High quality 10" neodymium woofer with 4" voice coil.
  • Class-D amplifier with DSP
  • High Frequency Setup
  • Low Cut
  • Sensitivity adjustable from 0dB to 10dB
  • XLR line input
  • Line output
  • Power indicator
  • Protection indicator
  • Limiter indicator
  • USB port
  • Power In/Out
  • Power switch

Technical specifications Atomic Pro Kira Top10

  • RMS power : 350W
  • Peak power : 700W
  • Frequency response +/-3dB : 65Hz-18KHz
  • Frequency Response -10dB : 50Hz-18KHz
  • Coverage: 100°x15°
  • SPL Max : 122dB / 138dB (peak)
  • Input: XLR 20KΩ balanced
  • Output: Balanced XLR
  • Cooling: passive radiator
  • Construction: 18mm plywood
  • Dimensions: 58x45.4x28.4cm
  • Weight: 25.5Kg

Technical specifications Atomic Pro Kira Sub18

  • RMS power : 1000W
  • Peak power : 1800W
  • Frequency response +/-3dB : 50Hz-100Hz
  • Frequency response -10dB : 45Hz-100Hz
  • SPL Max : 129dB / 136dB (peak)
  • Input: XLR 20KΩ balanced
  • Output: Balanced XLR
  • Cooling: passive radiator
  • Construction: 18mm plywood
  • Dimensions: 58x58x51cm
  • Weight: 41Kg
